NV9000-SE Utilities • User’s Guide 403
13. EC9700 and EC9710 Panels
Locating and Viewing Existing EC9700/EC9710 Panels
To narrow the list of panels that display, enter the first characters of a control panel name in the
‘Computer (or Windows User) Name Filter’ field. The list is automatically reduced to display
only panels matching that character string.
Figure 13-14. GUIs Table
Four columns display control panel information. Each row represents a single control panel:
3 Click
X
on the window title tab to close the table.
Column Description
ID The identification number automatically assigned the control panel in the NV9000-
SE system.
Computer (or
Windows User)
Name
The name of the computer on the network where the EC9700/EC9710 control panel
application resides.
User Name The user’s name. User names are managed through the ‘User’ table. (See Managing
User Names on page 509.)
Configuration The configuration file associated with the control panel. ‘For more information on
configuration files, see
Working With Configuration Files on page 19
Language Currently, only English is supported.
Description Optional description of the EC9700/EC9710 control panel.
Computer (or
Windows User)
Name
The name of the computer or the user’s name on the network where the EC9700/
EC9710panel application resides.
