488 Rev 3.0 • 25 Mar 10
16. Tielines
Managing Tieline Groups
The following tables display specific tieline information:
• ‘Tieline Group’ table — A list of existing tieline groups, one per row, with name, ID and
description.
• ‘Tieline Group Binding’ table — A list of each tieline in a group, one tieline per row. When a
tieline group is created, the tieline added to the group is “bound” to that group such that no
other group can use that tieline.
Viewing the ‘Tieline Group’ Table
1 Launch NV9000-SE. (See Launching and Exiting the Application on page 12.)
2 From the Navigation area, select the ‘Views’ pane and then ‘Tieline Group’. The ‘Tieline
Group’ table appears, as shown in Figure 16-25.
To narrow the list of tieline groups that display, enter the first characters of a tieline group name
in the ‘Name Filter’ field. The list is automatically reduced to display only tieline groups
matching that character string.
Figure 16-25. Tieline Group Table
Three columns display tieline information. Each row represents a single tieline group.
Column Description
ID Lists the ID number associated with the tieline group
Name Lists the name associated with the tieline group.
Description The description, if any, associated with the tieline group.
