NV9000-SE Utilities • User’s Guide 93
7. Routers
Updating Router Details
Figure 7-25. Physical Levels Section
5 Click Save to save your changes.
6 Click X on the window title tab to close the page.
How to Update Router Protects and Locks Using the ‘PhysLevel’ Table
1 Launch NV9000-SE. (See Launching and Exiting the Application on page 12.)
2 From the Navigation area, select the ‘Views’ pane and then ‘PhysLevels’. The ‘PhysLevels’
table appears, as shown in Figure 7-26.
To narrow the list of physical levels that display, enter the first characters of a physical level
name in the ‘Name Filter’ field. The list is automatically reduced to display only levels match-
ing that character string.
Figure 7-26. PhysLevels Table
Not all of the columns display in one screen. Use the scroll bar at the bottom of the screen to
view columns to the right or left.
