NV9000-SE Utilities • User’s Guide 277
11. Control Panels
Adding a Control Panel
NV9608
The ‘NV9608’ page determines how the NV9608 control panel functions and displays. For a full
description of the control panel and functions, see
NV9608 on page 528.
The ‘NV9608’ page is divided into sections:
• Button Layout — A graphic representation of the buttons on the control panel. Click on a button
to assign a function to it. Certain buttons have preassigned functions and cannot be changed.
• Button Definitions — Assigns a function to the currently selected button in the ‘Button Layout’
field. The options available as definitions change depending on the options selected in the
‘Panel Options’ section.
• Panel Options — Specifies control panel behavior, such as the default mode.
The control panel options, button layout and button definitions are configured using the ‘NV9608’
page. When saved, the configurations are communicated to the physical control panel and appear to
the operator using the control panel.
How to Configure a NV9608 Control Panel
1 Add a NV9608 control panel. (See Adding a Control Panel on page 240.)
Or
Locate the NV9608 control panel being updated. (See
How to Locate and View Existing Con-
trol Panels on page 347.)
Important When configuring the control panel, it is important to select control panel options
first. This determines the subsequent button definitions.
