NV9000-SE Utilities • User’s Guide 183
9. Devices
Device Connections Queries
Device Connections Queries
The ‘Queries & Advanced Operations’ folder, accessed through the ‘Views’ pane, performs queries
on device connections in the NV9000-SE system. Using the tables provided you can view a list of
device connections or a list of orphaned connections (those without an associated device). Devices
are grouped by level set, and connections (ports) are listed by the virtual level associated with a
port. Using the ‘Device Phys Conns’ table, files listing each device input and output connections
can be exported for reference outside the NV9000-SE system.
Device Physical Connections Query
The ‘Device Physical Connections’ table enables you to add devices, query device connections and
export the query for viewing. Physical connections queries list all devices included in the NV9000-
SE system.
How to Query Device Physical Connections
1 Launch NV9000-SE. (See Launching and Exiting the Application on page 12.)
2 From the Navigation area, select the ‘Views’ pane, then ‘Queries & Advanced Operations’ and
then ‘Device Physical Connections’. The ‘Device Physical Connections’ table displays, as
shown in
Device Physical Connections Table with Results on page 184.
