11. Control Panels
Adding a Control Panel
3 In the ‘Panel Options’ section, check a check box to select additional control panel behaviors
(un-check a check box to deselect an option):
Default
Destination
Last Selected
Panel remembers the last destination
selected and restores this after a reset.
None
After a reset, the control panel displays no
destination device. (Not recommended.)
‹device›
The Panel uses the specified device as the
destination after a reset. This also becomes
the destination controlled when the control
panel is set to single destination mode.
Status Monitor
None
Selected destination used as a monitor to
switch the source that is in ‘status’ mode
for the selected destination.
—
‹device›
Data Routing
Mode
Automatic
Routes made on the control level, if
present, occur automatically.
Semiautomatic
Routes made on the control level, if
present, require a confirmation before
being switched.
Manual
All routes made on the control level when
the source device is currently in-use are
performed as separate “takes”.
Default Name
Set
<name set>
The name set selected is applied to the
control panel. When a Name Set Toggle
button is added, it toggles between the
default name set and the system name set.
Check box
Description
Related Topic
User-
Programmable ID
When checked, the Panel ID can be changed locally at the
control panel itself. When unchecked, ID numbers can only
be changed by first entering the system PIN locally at the
control surface to temporarily enable ID changes.
—
Source Master
Default
Makes the source the controlling (or “master”) device
permanently. By default, ‘destination is master’ is selected.
(This option is specifically for use with a Miranda data router
or port switch.)
“Source is master” is used for duplication, or broadcast
routing, on the control level. “Destination is master” is for
machine-to-machine editing.
Note: “Source is master” mode reverses the direction of data
routing for devices used in data (control) level “takes”.
Note: If ‘Source Master Default’ is selected, the Source
Master button will not switch to “destination is master” mode
when pressed.
Hold Preset
Default
Makes any Hold button active when the control panel reverts
to its default state (after a Default State button is pressed, or
when the control panel is restarted).
Note: If this option is selected, it is recommended that a Hold
button be placed on the control panel.
Hide sources not
configured on this
panel
Hides name of all source devices that are not presently
configured. The control panel displays asterisks instead.
—
Field
Option
Description
Related Topic
