NV9000-SE Utilities • User’s Guide 309
11. Control Panels
Adding a Control Panel
5 If ‘Navigate’ was selected as a button type, define the button properties. Using the ‘Edit Navi-
gation Button’ dialog box, pages that create a “tree” can be selected. You can choose to have the
button jump to a new page or an existing page, creating “child” pages to “parent” pages. For
instructions, see
Creating a “Tree” of Pages on page 342.
6 Enter destination numbers for multi-destination switching:
Quick Source All modes Immediately presets the source defined without
having to first select a category and then select a
device. From the drop-down list, select the
source device.
—
Salvo All modes Places the control panel in ‘Salvo’ mode. The
button is required if you want access to system
salvos.
When you assign ‘Salvo’ to a button, a drop-
down list appears in which you select a salvo
ID.
Salvos on page 364
and
Salvos on page 431
Save Preset All modes When on, this button causes the control panel to
save whatever source is in the ‘Preset’ column,
so that if the control panel is reset, that source
reappears. When off, the presets are not saved.
—
Selection All modes Displays and enables operator to select items
from the list that displays. For example, a list of
salvos. —
Source All modes Loads a predefined source device into the preset
column, ready for selection by pressing Take.
When you assign ‘Source’ to a button, a drop-
down list appears in which you select a
source(s). Select a level from ‘Level Set Filter’
to limit the sources to only those assigned to that
level. (The same is true if selecting destinations
in MD mode.)
Source on page 365
Source Master All modes The button reverses the direction of data routing
for devices used in data (control) level "takes".
For example, if the (controlling) destination is
the master and the (controlled) source is the
slave, pressing Source Master reverses the
roles.
Source Master on
page 365
Source/
Destination
All modes Button is either a single source or a single
destination depending on the operating mode.
Source/Destination
on page 365
Take All modes Switches the loaded preset source device(s) to
the selected destination device on all levels that
have a preset loaded. The ‘Status’ column
changes to the new device(s).
Take on page 366
Undefined All modes Makes the button undefined and inactive. It will
remain unlit.
—
XY / MD
Mode All modes Switches control panel between XY and multi-
destination modes. Modes of Operation
on page 357
Button Modes Description Related Topic
