NV9000-SE Utilities • User’s Guide 91
7. Routers
Updating Router Details
4 Click
Save
.
Or
To revert to previously saved configuration, click
Revert to Saved .
5 Click
X
on the window title tab to close the table.
Updating Protects and Locks
Inputs and outputs can be protected or locked. When protected, changes can only be made by per-
sons with proper authorization. When locked, no one can make changes, even those persons who
have authorization to make changes under a protect status.
Router protects and locks are updated using the ‘Routers’ page accessed through the ‘Configura-
tion’ pane or the ‘PhyLevels’ table accessed through the ‘Views’ pane.
How to update router protects and locks using the ‘Routers’ page
1 Launch NV9000-SE. (See Launching and Exiting the Application on page 12.)
2 From the Navigation area, select the ‘Configuration’ pane and then ‘Routers’. The ‘Routers’
page displays, as shown in Figure 7-24.
To narrow the list of routers that display, enter the first characters of a router name in the ‘Name
Filter’ field. The list is automatically reduced to display only routers matching that character
string.
Or
Output Protect Protects and/or locks outputs. When locked it
cannot be changed. When protected, changes can
only be made with proper authorization. See
Locking and Protecting Panels on page 232.
From the drop-down list, select:
Disabled
— Removes protect and
unlocks.
In Server
— Enables protect and
lock in the server.
In Router
— Enables protect and
lock in the router.
Output Lock
Shared
Control
Informs the NV9000 whether another control
system is connected to this physical level.
From the drop-down list, select:
True
— Another control system is
connected to the router control
card that can initiate crosspoint
changes. The NV9000 allows it
and updates its tables periodically
with these changes. (Unexpected
changes are not logged as errors.)
False
— The NV9000 manages
this physical level exclusively,
and does not permit crosspoint
changes that it does not initiate.
Field Description Values
