NV9000-SE Utilities • User’s Guide 203
10. Categories
Using Global Suffix Pages
How to Create a Global Suffix Page
1 Launch NV9000-SE. (See Launching and Exiting the Application on page 12.)
2 From the Navigation area, select the ‘Tasks’ pane and then ‘Add Control Panel’.
Or
From the Navigation area, select the ‘Configuration’ pane and then ‘Control Panels’. The ‘Con-
trol Panels’ page displays. On the ‘Control Panels’ page, click
Add Control Panel .
The ‘Add Control Panel’ page appears:
Figure 10-10. Add Control Panel Page
3 Enter information in the fields provided. Entries must be entered in all active fields:
Field Description
Type From the drop-down list, select either NV9640, NV9641 or NV9642.When saved, the
Global Suffix page can be applied to other control panels of the same type.
ID Enter a unique identification number up to five digits long. Do not use punctuation
marks or symbols.
Name Enter a unique and descriptive name for the Global Suffix page, up to 8 characters long.
Do not use punctuation marks or symbols.
User By default, only the user type ‘EnvyUser’ is supported at this time. For more
information, see
Managing User Names on page 509.
Configuration
Options Select ‘New (default), named’ and enter the name of the Global Suffix page you are
creating.
