NV9000-SE Utilities • User’s Guide 233
11. Control Panels
Creating Button Legends
Currently Supported Panels
NV9000-SE currently supports a wide variety of control panels. Each control panel type has a dif-
ferent layout, operation mode and button options to meet your unique needs.
The following is a brief description of each control panel:
Creating Button Legends
If using the hardware version of a control panel, you can create button legends at any time using a
desktop publishing application. The legends should be transparent and no larger than 0.40
″× 0.40″
(10mm square). A 3/8 ″ (9.5mm) square insert allows for a little clearance. The clear plastic mate-
rial used for overhead transparencies is suitable for printing legends.
Button legends that appear on the virtual version of a control panel are based on defaults within the
NV9000-SE system. Virtual panel button legends cannot be changed.
For a list of default button text, see Button Functions on page 359.
Panel Name Description Related Topic
NV9601 X-Y /Multi-destination 2RU control panel with 42 characters
by 8 lines
NV9601 on page 517
NV9602 Multi-mode 1RU control panel with 8-character displays NV9602 on page 519
NV9603 X-Y control panel with 8-character displays NV9603 on page 521
NV9604 Multi-mode 1RU control panel NV9604 on page 522
NV9605 Single-mode 1RU control panel with 3-line by 8-character
displays NV9605 on page 524
NV9606 Multi-mode 1RU control panel with 68 buttons NV9606 on page 525
NV9607 Multi-mode 2RU control panel with 16 buttons NV9607 on page 526
NV9608 X-Y /Multi-destination 2RU control panel with 8 LCD buttons NV9608 on page 528
NV9609 X-Y control panel with 8-character displays NV9609 on page 531
NV9616 X-Y /Multi-destination 2RU control panel with 16 LCD
buttons NV9616 on page 532
NVRP16 Remote panel module that sends “take” or “lock” messages to a
network of routers. RP16 and RP32 on page
535
NVRP32
NV9640 X-Y /Multi-destination 2RU panel with 42 characters by 8 lines NV9640 on page 535
NV9641 X-Y/Multi-destination 1RU panel with 16 LCD function
buttons NV9641 on page 538
NV9642 X-Y/Multi-destination 1RU panel with 34 LCD function
buttons and VFD display.
NV9642 on page 541
NV9660 Hybrid 2RU panel combining audio mixer panel and router
control panel NV9660 on page 545
NV9575-VF 1RU tally expander featuring 64 relay outputs and 32
optionally isolated inputs NV9575-VF on page 548
