244 Rev 3.0 • 25 Mar 10
11. Control Panels
Adding a Control Panel
Release Mode Normal Release This control panel can only release “locks”
and “protects” set at the control panel itself
(by the assigned user). A user who has the
correct PIN can enable ‘Force Release’
temporarily, allowing the removing of locks
and protects set by any user.
Locks on page
362
and
Protect on page
363
and
Force Release on
page 360
Force Release This control panel can release locks and
protects set by any user. We recommend that
you use ‘Normal Release’ mode and assign a
PIN to allow access to the ‘Force Release’
function.
Default
Destination Last Selected The control panel remembers the last
destination selected and restores this after a
reset. Default State on
page 356
None After a reset, the control panel displays no
destination device. (Not recommended)
‹device› The control panel uses the specified device
as the destination after a reset.
X-Y Data
Routing Mode Automatic If a data level is involved in the route,
connects the source to the destination,
regardless of who is currently using the
devices.
Default Routing
on page 357
and
Modes of
Operation
on
page 357
Semi-automatic If the device to be acquired is already in use
on the data level, the user is alerted. The user
can perform the route by pressing Take a
second time. If Take is not pressed again, the
route is cancelled. If the device is not in use,
the “take” occurs automatically.
(Recommended)
Manual All takes on the data level must be performed
manually as breakaways. The data level will
never switch as part of a multi-level “take”.
MD Data
Routing Mode Automatic If a data level is involved in the multi-
destination route, connects the source to the
destinations, regardless of who is currently
using the devices. (Recommended)
Default Routing
on page 357
and
Modes of
Operation
on
page 357
Manual All multi-destination takes on the data level
must be performed manually as breakaways.
The data level will never switch as part of a
multi-level “take.”
Default Name
Set
‹name set› The name set selected is applied to the
control panel. When a Name Set Toggle
button is added, it toggles between the
default name set and the system name set.
Name Set Toggle
on page 363
Multidest Device
Limit (fixed at 8
presently) The maximum number of MD entries
allowed. 16 pages, 8 per page provides 128
maximum (Range 1–128). The default is 8.
See Step 5 for the related entry fields. NV9601 on page
517
Field Option Description Related Topic
