Grass Valley NV9000-SE v.3.0 - Manual (Page 68)

48 Rev 3.0 • 25 Mar 10
5. System Management
Managing System Parameters
How to Delete a Host
1 Launch NV9000-SE. (See Launching and Exiting the Application on page 12.)
2 From the Navigation area, select the ‘Views’ pane and then ‘Hosts’. The ‘Hosts’ table appears,
as shown in Figure 5-7.
All hosts currently defined in the system are listed. To narrow the list, enter the first characters
of the host’s name in the ‘Computer Name Filter’ field. The list is automatically reduced to dis-
play only hosts matching that character string.
Figure 5-7. Hosts Table
3 Click anywhere in the row listing the host being deleted.
4 Click
Delete
. The row is removed.
5 Click
Save
.
Or
To revert to previously saved configuration, click
Revert to Saved
.
6 Click
X
on the window title tab to close the table.
Managing System Parameters
The ‘SysParams’ table accessed through the ‘Views’ pane enables you to view current system
parameters for the NV9000-SE system. System parameters include values for system wide settings,
such as default time out to lock a control panel when the panel is inactive.
