452 Rev 3.0 • 25 Mar 10
15. Salvos
Updating Salvo Information
The ‘Salvo Details’ page has four sections:
• Sources — Lists all source devices in the upper region and all virtual levels associated with
those devices in the lower region. (See About Devices on page 158 and Physical Levels vs.
Virtual Levels on page 112.)
• Destinations — Lists all destination devices in the upper region and all virtual levels
associated with those devices in the lower region. (See About Devices on page 158 and
Physical Levels vs. Virtual Levels on page 112.)
• Current Salvo Operations — Options for selected actions.
• Salvo Description — Brief description of the selected actions.
The fields in the ‘Sources’ sections change depending on the option selected in the ‘Current
Salvo Operation’ section. As options are selected in the ‘Current Salvo Operation’ section, a
description of the operation appears in the ‘Salvo Description’ section.
4 Update salvo action, as needed.
a Select the radio button corresponding to view the action, if any, that you want, as follows:
Option
Source or
Destination
Description Related Topic
Take Sources/
Destinations Switches the loaded preset source device(s)
to the selected destination device on all
levels that have a preset loaded. The ‘Status’
column changes to the new device(s).
Take on page 366
Source Lock Sources only Enables any Lock button to lock sources on
the control panel. If ‘Enable Source Lock’ is
not selected, the Lock button cannot be used
to lock sources on the panel.
Locks on page 362
Source Protect Sources only Enables any Protect button to protect
sources on the panel. If ‘Enable Source
Protect’ is not selected, the Protect button
cannot be used to protect sources on the
panel.
Protect on page 363
Source
Release
Sources only The panel can release source locks and
protects set only at the panel itself (by the
assigned user). A user who has the correct
PIN can enable ‘Force Release’ temporarily,
allowing the removing of locks and protects
set by any user.
Locks on page 362
and
Protect on page 363
and
Force Release on
page 360
Source Force
Release
Sources only Enables this panel to release any source
locks and protects set by any user.
Miranda recommends that you use ‘Source
Release’ mode and assign a PIN to allow
access to the ‘Force Release’ function.
Force Release on
page 360
Destination
Lock Destinations
only Enables any Destination Lock button to
function. If ‘Enable Destination Lock’ is not
selected, the Destination Lock button will
not function on the panel.
Locks on page 362
Destination
Protect Destinations
only Enables any Destination Protect button to
function. If ‘Enable Destination Protect’ is
not selected, the Destination Protect button
will not function on the panel.
Protect on page 363
