256 Rev 3.0 • 25 Mar 10
11. Control Panels
Adding a Control Panel
5 Click
Save
.
Or
To revert to the previously saved configuration, click
Revert to Saved
.
6 Click
X
on the window title tab to close the page.
NV9603
The ‘NV9603’ page determines how the NV9603 control panel functions and displays. For a full
description of the control panel and functions, see
NV9603 on page 521.
The ‘NV9603’ page is divided into sections:
• Button Layout — A graphic representation of the control panel. Click on a button to assign a
function to it. Certain buttons have preassigned functions and cannot be changed.
• Button Definitions — Assigns a function to the currently selected button in the ‘Button Layout’
field. The options available as definitions change depending on the options selected in the
‘Panel Options’ section.
• Panel Options — Specifies control panel behavior, such as the mode of operation and default
mode.
The control panel options, button layout and button definitions are configured using the ‘NV9603’
page. When saved, the configurations are communicated to the physical control panel and appear to
the operator using the control panel
Source All modes Loads a predefined source device into the
preset column, ready for selection by
pressing Take.
When you assign ‘Source’ to a button, a
drop-down list appears in which you select a
source(s). Select a level from ‘Level Set
Filter’ to limit the sources to only those
assigned to that level. (The same is true if
selecting destinations in MD mode.)
Source on page
365
Source Master All modes The button reverses the direction of data
routing for devices used in data (control)
level "takes". For example, if the
(controlling) destination is the master and the
(controlled) source is the slave, pressing
Source Master reverses the roles.
Source Master on
page 365
Source Shift All modes Allows the operator to select the second
source device mapped to a source button.
Two sets of source devices can be
programmed. The button toggles between the
“unshifted” set and the “shifted” set.
Source Shift on
page 365
Undefined All modes Makes the button undefined and inactive. It
will remain unlit. —
Button Modes Description Related Topic
