2. Using the Interface
The SE Utilities Window
The SE Utilities Window
The NV9000-SE interface is divided into two main areas: a navigation area and a work area, as
shown in Figure 2-1. When the application first launches, the work area is blank. A menu bar at the
top of the screen provides quick access to general tasks, such as opening, closing and saving files.
Figure 2-1. NV9000-SE Window
Navigation Area
The navigation area features four sections, called “panes.” Clicking on a pane slides it up to the top
of the navigation area to display a list of options. In Figure 2-1, the ‘Configuration’ pane has been
clicked, displaying a list of options related to configuration tasks. Clicking on an option title opens
related tabbed pages in the work area.
To scroll through panes in the navigation area, press CTRL+Tab on your keyboard.
Work Area
The work area displays tabbed windows (pages). In general, there are three types of windows that
display:
• Pages — Lists all items of a selected type in the system or details for a selected item. Manages
almost all information for a selected, single item.
• Table — Lists all items of a selected type in the system, based on specific, limited criteria, and
manages very specific information.
• Wizard — A step-by-step guide that helps you perform a specific configuration task quickly and
accurately.
Pages, tables and wizards share databases so that changes in one interface updates all correspond-
ing fields in all related interfaces.
To advance from field to field on a page, press TAB on your keyboard. To move between fields, but
in reverse, press SHIFT+TAB.
Menu Bar
Navigation
Area
Pane
Work Area
