162 Rev 3.0 • 25 Mar 10
9. Devices
Adding a Device
There are two sections: ‘Device Info’ and ‘Device Level Detail’. Enter information in the fields
provided, as follows:
6 Click
Save
to save your changes.
7 Click
X
on the window title tab to close the page.
How to Add a Class of Devices Using the ‘Add Multiple Devices’ Wizard
The process for adding a class of devices involves two general tasks:
• First, the name for the class of devices, the number of devices, and the level set to which the
devices belong are specified.
• Second, the input and output connector numbers for the virtual levels of the devices are speci-
fied.
All devices must be of the same type. For example, 6 monitors can be added at one time, or 8 VTRs
can be added at one time. However, both monitors and VTRs cannot be added at the same time.
1 Launch NV9000-SE. (See Launching and Exiting the Application on page 12.)
2 From the Navigation area, select the ‘Tasks’ pane and then ‘Add Multiple Devices’.
Section Field Description
Device Info Name The name assigned to the device. The information entered in the ‘Add
Device’ page displays. You can change it here at this time.
Description A brief description of the device, such as VTR, etc. The information
entered in the ‘Add Device’ page displays. You can change it here at
this time.
Level Sets The level set assigned to the device. Level sets are composed of virtual
levels that define signal types. The information entered in the ‘Add
Device’ page displays. You can change it here at this time.
For more information on level sets, see
About Levels and Level Sets
on page 112.
Categories The categories assigned to the device. When adding a device for the
first time, this field will be blank. For instructions on how to assign
categories, see
Adding Categories on page 190.
Device Level
Detail Level Displays each virtual level in the level set assigned to the device. For
more information on virtual levels, see
Physical Levels vs. Virtual
Levels on page 112.
Input Enter the router’s input or output number associated with the virtual
level. The number is the number of the physical port where the cable
connects from the device to the router.
Source devices are connected to router inputs; destination devices are
connected to router outputs. Some devices have both inputs and
outputs, in which case an entry appears in both columns.
Output
