NV9000-SE Utilities • User’s Guide 467
16. Tielines
Locating and Viewing Existing Tieline Details
To narrow the list of tielines that display, enter the first characters of a tieline name in the
‘Name Filter’ field. The list is automatically reduced to display only tielines matching that
character string.
Figure 16-6. Tieline Table
Four columns display tieline information. Each row represents a single tieline.
3 Click
X
on the window title tab to close the table.
Viewing the ‘Tieline Path’ Table
1 Launch NV9000-SE. (See Launching and Exiting the Application on page 12.)
2 From the Navigation area, select the ‘Views’ pane and then ‘Tieline Path’. The ‘Tieline Path’
table appears, as shown in Figure 16-7.
To narrow the list of tielines that display, enter the first characters of a source (upstream) physi-
cal level in the ‘Source Phys Level Filter’ field.
Or
Enter the first characters of a source signal type in the ‘Source Signal Type Filter’ field.
Or
Column Description
ID Lists the ID number associated with the tieline
Cost The numeric “weight” assigned to the tieline. (See Costs on page 457.)
Name Lists the name associated with the tieline.
Description The description, if any, associated with the tieline.
