NV9000-SE Utilities • User’s Guide 425
14. External Interfaces
Updating External Interface Information
How to Update the External Interface Control Point
1 Launch NV9000-SE. (See Launching and Exiting the Application on page 12.)
2 From the Navigation area, select the ‘Views’ pane and then ‘Apps’. The ‘Apps’ table appears,
as shown in Figure 14-18.
To narrow the list of external interfaces that display, enter the first characters of an external
interface name in the ‘Name Filter’ field. The list is automatically reduced to display only
external interfaces matching that character string.
Figure 14-18. Apps Table
3 Locate the row listing the external device being updated.
4 In the ‘Control Point’ column, click in the field to activate it and select a control point from the
drop down list.
5 Click
Save
.
Or
To revert to previously saved configuration, click
Revert to Saved .
6 Click
X
on the window title tab to close the table.
Changing the Run Condition or Run Priority
The run condition determines if the application starts automatically upon booting up the system.
The run priority determines if requests initiated by the application are performed before requests
from other applications or in the order received. Run condition and run priority can be changed
using the ‘Apps’ table accessed through the ‘Views’ pane.
How to Update the Run Condition or Run Priority
1 Launch NV9000-SE. (See Launching and Exiting the Application on page 12.)
2 From the Navigation area, select the ‘Views’ pane and then ‘Apps’. The ‘Apps’ table appears,
as shown in Figure 14-19.
