NV9000-SE Utilities • User’s Guide 493
16. Tielines
Managing Tieline Groups
How to Add or Remove Tielines in Tieline Groups
1 Launch NV9000-SE. (See Launching and Exiting the Application on page 12.)
2 From the Navigation area, select the ‘Configuration’ pane and then ‘Tieline Groups’. The
‘Tieline Groups’ page displays, as shown in Figure 16-29. All tieline groups currently defined
in the system are listed.
To narrow the list, enter the first characters of the tieline group’s name in the ‘Name Filter’
field. The list is automatically reduced to display only tieline groups matching that character
string.
Figure 16-29. Tieline Group Page
The ‘Name’ column lists the name assigned the tieline group in NV9000-SE.
3 Double click on a single row to view details for that tieline group in the ‘Tieline Group Detail’
page, as shown in Figure 16-30.
Or
Click anywhere in the row listing the tieline group being viewed and click
Edit Selected Tieline
.
Use the ‘Shift’ or ‘Ctrl’ key on your keyboard to select multiple tieline groups. Each tieline
group opens in a separate tabbed window. Click the tab to bring the window forward.
4 If adding a tieline, select a tieline from the ‘Tielines Available’ list and click the left facing
arrow. The tieline appears in the ‘Tielines in Group’ list.
