NV9000-SE Utilities • User’s Guide 35
5. System Management
Managing System Controllers
Managing System Controllers
The ‘System Management’ page displays information about a system controller in addition to pro-
viding access to system controller controls.
Figure 5-1. Example of System Management Page
The ‘System Management’ page displays the following information:
Section Description Related Topic
Controller Summary Lists the IP address currently assigned to each system
controller added to NV9000-SE, including the “health”
of the connection and whether the system controller is
currently active. Each system controller is assigned an
identification number, listed in the ‘Controller Number’
field.
Any faults or issues are listed in the ‘Controller Faults’
area below the summary fields.
Changing System
Controller IP
Address or Name
on
page 39
Router Summary Lists all routers currently added to NV9000-SE. The
‘Active On’ column lists which system controller is
assigned to each router. Routers on page 61
Panel Summary Lists all control panels currently added and which system
controller it is connected to. A “0” denotes no
connection. Control Panels on
page 231
