NV9000-SE Utilities • User’s Guide 259
11. Control Panels
Adding a Control Panel
4 In the ‘Button Layout’ section, select a blank button and then in the ‘Button Definitions’ sec-
tion, select a definition for the button from the drop-down list. The button definition appears on
the selected button in the ‘Button Layout’ section.
There are two classes of buttons:
• Those that assign a dedicated function to a button directly, such as ‘Def State’ (default state)
or ‘Clear’. No other options are available.
• Those that define a variable function, such as ‘Category’. Additional options display
enabling you to define the variables.
Select from the following button options:
Hide sources not
configured on this
panel
Hides name of all source devices that are not presently
configured. The control panel displays asterisks instead.
—
Use Continuous
Scrolling If checked, the panel scrolls source or destination devices
continuously. That is, the display shows the first device in the
list following the last when scrolling up, and shows the last
device after the first if scrolling down.
If unchecked, the panel stops scrolling when it reaches either
the beginning or end of the list.
This option does not affect scrolling of salvos when the panel
is in salvo mode or levels when the panel is in level mode.
—
Button Description Related Topic
Broadcast On the data (control) level, assigns one controlling device
(master) to multiple controlled devices (slaves). Useful in
dubbing and editing applications. Status is only reported from
the first assigned slave.
Broadcast on page
359
Category Selects a category (and its device list). Separate categories are
permitted for source and destination devices.
When you assign a category button, three additional drop-
down menus appear: ‘Source Category’, ‘Destination
Category’ and ‘Suffix’. Choose one of the categories (or
none) from the category lists. Choose one of the suffixes (or
none) from the suffix list.
Select a level from the ‘Level Set Filter’ to limit categories to
only those in the selected level.
Category on page
359
Chop When supported by the router, the button is a toggle that
enables and disables rapid switching of the selected
destination device between the current source and the preset
source. Used to test system timing.
Chop on page 360
Destination Selects a destination device. Choose a destination from the
drop-down list. An optional ‘Level Set Filter’ may be selected
to limit the devices that display to only those in the selected
level sets.
Level Sets on page
111
Destination Lock Sets or removes a “lock” on the current destination device. Locks on page 362
Destination Mode This (required) button initiates the destination selection
sequence, and lights all valid category buttons in amber.
Operators choose the desired destination in XY mode, or the
destination to add in ‘Multidest’ mode.
Destination Mode
on page 360
and
Modes of Operation
on page 357
Check box Description Related Topic
