64 Rev 3.0 • 25 Mar 10
7. Routers
Adding a Router
levels, are added. Router details are added using the ‘Routers’ page accessed through the ‘Configu-
ration’ pane.
How to Add a Router Using the ‘Add Router’ Wizard or ‘Routers’ Page
1 Launch NV9000-SE. (See Launching and Exiting the Application on page 12.)
2 From the Navigation area, select the ‘Tasks’ pane and then ‘Add Router’.
Or
From the Navigation area, select the ‘Configuration’ pane and then ‘Routers’. The ‘Routers’
page displays. On the ‘Routers’ page, click
Add Router
.
The ‘Add Router’ page appears:
Figure 7-2. Add Router Page
3 Enter information in the fields provided (Red titles denote required fields):
Field Description
Name Enter the name used to describe the router. Be sure to use a unique name that is
descriptive. The name is limited to 8 characters. Do not use punctuation marks or
symbols.
Router Host From the drop-down list, select the router’s host. There is generally only one:
NVCONFIG.
