NV9000-SE Utilities • User’s Guide 273
11. Control Panels
Adding a Control Panel
3 In the ‘Panel Options’ section, check a check box to select additional control panel behaviors
(un-check a check box to deselect an option):
Default
Destination
None After a reset, the control panel displays no
destination device. (Not recommended.)
Default State on
page 356
‹device› The control panel uses the specified device
as the destination after a reset. This also
becomes the destination controlled when
the control panel is set to single destination
mode.
Status Monitor None Selected destination used as a monitor to
switch the source that is in ‘status’ mode
for the selected destination.
—
‹device›
Data Routing
Mode
Automatic X-Y mode routes made on the control
level, if present, occur automatically.
Default Routing on
page 357
Semiautomatic X-Y mode routes made on the control
level, if present, require a confirmation
before being switched.
Manual All X-Y routes made on the control level
when the source device is currently in-use
are performed as separate takes.
Default Name
Set <name set> The name set selected is applied to the
control panel. When a Name Set Toggle
button is added, it toggles between the
default name set and the system name set.
Name Set Toggle on
page 363
Check box Description Related Topic
User-
Programmable ID When checked, the Panel ID can be changed locally at the
control panel itself. When unchecked, ID numbers can only
be changed by first entering the system PIN locally at the
control surface to temporarily enable ID changes.
—
Source Master
Default Makes the source the controlling (or “master”) device
permanently. By default, ‘destination is master’ is selected.
(This option is specifically for use with a Miranda data router
or port switch.)
“Source is master” is used for duplication, or broadcast
routing, on the control level. “Destination is master” is for
machine-to-machine editing.
Note: “Source is master” mode reverses the direction of data
routing for devices used in data (control) level “takes”.
Note: If ‘Source Master Default’ is selected, the Source
Master button will not switch to “destination is master” mode
when pressed.
Source Master on
page 365
Hold Preset
Default Makes any Hold button active when the control panel reverts
to its default state (after a Default State button is pressed, or
when the control panel is restarted).
Note: If this option is selected, it is recommended that a Hold
button be placed on the control panel.
Hold on page 361
Default State on
page 360
Field Option Description Related Topic
