122 Rev 3.0 • 25 Mar 10
8. Level Sets
Locating and Viewing Level Sets
Three columns display level set information. Each row represents a single level set.
3 Click X on the window title tab to close the table.
How to Locate Level Sets Using the ‘Level Set Details’ Table
1 Launch NV9000-SE. (See Launching and Exiting the Application on page 12.)
2 From the Navigation area, select the ‘Views’ pane and then ‘Level Set Details’. The ‘Level Set
Details’ table appears, as shown in Figure 8-8.
All level sets currently defined in the system are listed. To narrow the list, enter the first charac-
ters of the level set name in the ‘Level Set Filter’ field.
Or
Enter the first characters of a virtual level contained in the level set in the ‘Virtual Level Filter’
field.
Or
Enter the first characters of a physical level mapped to a virtual level in the level set in the
‘Phys Level Filter’ field.
The list is automatically reduced to display only level sets matching that character string.
Figure 8-8. Level Set Details Table
Column Description
ID Lists the ID number associated with the level set.
Name Lists the name associated with the level set.
