NV9000-SE Utilities • User’s Guide 455
15. Salvos
Deleting Salvos
NV9000-SE uses a relational database. This means that if a record is referenced by another record,
the deletion will not be allowed. If there are dependencies, when the deletion is attempted,
NV9000-SE informs you of the dependencies. Delete the dependencies first, then delete the origi-
nally selected record.
Salvos can be deleted using the ‘Salvos’ page accessed through the ‘Configuration’ pane or using
the ‘Salvos’ table accessed through the ‘Views’ pane.
How to Delete a Salvo Using the ‘Salvos’ Page
1 Launch NV9000-SE. (See Launching and Exiting the Application on page 12.)
2 From the Navigation area, select the ‘Configuration’ pane and then ‘Salvos’. The ‘Salvos’ page
displays, as shown in Figure 15-20.
To narrow the list of salvos that display, enter the first characters of a salvo name in the ‘Mne-
monic Filter’ field.
The list is automatically reduced to display only salvos matching that character string.
Figure 15-20. Salvos Page
3 Click anywhere in the row listing the salvo being deleted and click Delete Salvo .
4 On the confirmation dialog box, click
Delete
.
5 Click
X
on the window title tab to close the page.
How to Delete a Salvo Using the ‘Salvos’ Table
1 Launch NV9000-SE. (See Launching and Exiting the Application on page 12.)
2 From the Navigation area, select the ‘Views’ pane and then ‘Salvo’. The ‘Salvo’ table appears,
as shown in Figure 15-21.
