11. Control Panels
Adding a Control Panel
NV9605
The ‘NV9605’ page determines how the NV9605 control panel functions and displays. For a full
description of the control panel and functions, see
NV9605 on page 524.
The ‘NV9605’ page is divided into sections:
• Button Layout — A graphic representation of the control panel buttons. The default ‘Page Up’
and ‘Page Down’ buttons scroll through four “pages” of button functions with each page
appearing in the left-most 32 buttons. These may not be changed.
• Button Definitions — Assign a function to the currently selected button in the ‘Button Layout’
field. The options available as definitions change depending on the options selected in the
‘Panel Options’ section.
• Outputs — The general-purpose I/O (GPIO) output connections at the rear of the control panel.
• Inputs — The general-purpose I/O (GPIO) input connections at the rear of the control panel.
• Panel Options — Specify control panel behavior, such as default mode.
The control panel options, button layout and button definitions are configured using the ‘NV9605’
page. When saved, the configurations are communicated to the physical control panel and appear to
the operator using the control panel.
How to Configure a NV9605 Control Panel
1 Add a NV9605 control panel. (See Adding a Control Panel on page 240.)
Or
Locate the NV9605 control panel being updated. (See
How to Locate and View Existing Con-
trol Panels on page 347.)
Important When configuring the control panel, it is important to select control panel options
first. This determines the subsequent button definitions.
