NV9000-SE Utilities • User’s Guide 433
15. Salvos
Creating a Salvo
Or
From the Navigation area, select the ‘Configuration’ pane and then ‘Salvo’. The ‘Salvo’ page
displays. On the ‘Salvo’ page, click
Add Salvo
. The ‘Add Salvo’ page appears:
Figure 15-1. Add Salvo Page
3 Enter information in the fields provided:
4 (Optional) Check the ‘Copy existing salvo’ check box and select a salvo from the drop-down
list. The new salvo will have the same configuration as the selected salvo. You can then change
the new salvo as needed.
5 Click
Next
. The ‘Salvo Details’ page appears, as shown in Figure 15-2.
Or
Click
Finish
. This adds the salvo name and description to the NV9000-SE system and clears all
fields so that another salvo can be added immediately. However, no salvo actions (commands),
are added. To add details to a salvo, locate the salvo and perform steps 5 through 8 as described
in this procedure. (See
How to Locate and View Existing Salvos Using the ‘Salvos’ Page on
page 438.)
Or
Field Description
Salvo Mnemonic Enter a name for the salvo. The name is limited to 8 characters. Do not use
punctuation marks or symbols.
Salvo Description Enter an optional description of the salvo.
