NV9000-SE Utilities • User’s Guide 489
16. Tielines
Managing Tieline Groups
3 Click
X
on the window title tab to close the table.
Viewing the ‘Tieline Group Binding’ Table
1 Launch NV9000-SE. (See Launching and Exiting the Application on page 12.)
2 From the Navigation area, select the ‘Views’ pane and then ‘Tieline Group Binding’. The
‘Tieline Group Binding’ table appears, as shown in Figure 16-26.
To narrow the list of tieline groups that display, enter the first character of a tieline group name
in the ‘Group Filter’ field.
And/Or
Enter the first characters of an individual tieline in the ‘Tieline Filter’ field.
The list is automatically reduced to display only tieline groups matching those character strings
entered.
Figure 16-26. Tieline Group Binding Table
Two columns display tieline group information. Each row represents a single tieline.
3 Click
X
on the window title tab to close the table.
Column Description
Group The name of the tieline group to which the tieline listed on the same row belongs.
Tieline The name of the tieline.
