NV9000-SE Utilities • User’s Guide 205
10. Categories
Using Global Suffix Pages
Select from the following button options:
10 Click
Save
. When creating a control configuration of that same type as selected for the Global
Suffix page — NV9640, NV9641 or NV9642 — the ‘ Use global suffix page to select devices’ check
box can be selected to apply the Global Suffix page to the control panel.
Button Description Related Topic
Back
(mandatory) Returns the control panel user to the previous “page” in the
“tree.”
A Global Suffix page must have a
Back
button.
Creating a “Tree”
of Pages on page
342
Category Unlike in other control panel configuration pages, this button is
used to select suffixes and add them to the control panel. A
‘Suffix’ drop-down list appears. Select a suffix from the list.
Using Categories
and Suffixes on page
190\
and
Using Global Suffix
Pages
on page 202
Clear Preset Erases entries in the control panel’s ‘Preset’ column, while
leaving the control panel in the same mode. Recommended as a
“safety” button.
Clear Preset on page
360
Hold Retains preset information after Take is pressed. Useful when
routing the same source to many destinations.
Hold on page 361
Take Switches the loaded preset source device(s) to the selected
destination device on all levels that have a preset loaded. The
‘Status’ column changes to the new device(s).
Take on page 366
Undefined Makes the button undefined and inactive. It will remain unlit. —
