NV9000-SE Utilities • User’s Guide 247
11. Control Panels
Adding a Control Panel
Chop All modes When supported by the router, the button is a toggle
that enables and disables rapid switching of the
selected destination device between the current
source and the preset source. Used to test system
timing.
Chop on page 360
Clear All modes Clears the last input in a series of entries. Press
repeatedly to clear an entire sequence. Clear on page 360
Clear Preset All modes Erases entries in the control panel’s ‘Preset’
column, while leaving the control panel in the same
mode. Recommended as a “safety” button.
Clear Preset on page
360
Default State All modes Returns the control panel to its pre-defined state. Default State on
page 360
Destination All modes Assigns a destination device to this control panel. --
Destination
Lock
All modes Sets or removes a “lock” on current destination
device. The lock can only be removed at the control
panel that originally set the lock, or by a control
panel that has ‘Force Release’ enabled. An “L” on
the control panel display indicates a “lock”.
Locks on page 362
Destination
Mode All modes This button initiates the destination selection
sequence, and lights all valid category buttons in
amber. Operators choose the desired destination in
XY mode, or the destination to add in multi-
destination mode.
Destination Mode
on page 360
Destination
Protect All modes Sets or removes a “protect” on current destination
device. The protect can only be removed at the
control panel that originally set the protect, or by a
control panel that has ‘Force Release’ enabled. A
“P” on the control panel display indicates a
“protect”.
Protect on page 363
Free Source All modes Defines a phantom device that can be used to
release or “free” devices on the data (control) level.
A free source is also used with tielines to free the
tieline for others to use. The free source is
configured in the Level Sets page.
Free Source on page
361
and
Level Sets on page
111
Hold All modes Retains preset information after Take is pressed.
Useful when routing the same source to many
destinations.
Hold on page 361
Information All modes Panel mode is changed to display system messages.
This button toggles between current control panel
mode and the info screen. A “+” sign indicates
messages are present. The Info button lights when
messages are available for viewing.
Information on page
361
Level Map All modes Cross-connects levels (typically in the same
physical router). Typically used to shuffle audio
channels, for example, to connect AES1/2 to AES3/
4. When an Info button is configured, you can view
current cross-connects. The ‘Level’ mode is
cancelled when the next normal “take” is performed
involving the selected devices. (The Level Map
button becomes enabled only when there is a valid
preset.)
Level Mapping on
page 362
Button Modes Description Related Topic
