Grass Valley NV9000-SE v.3.0 - Manual (Page 507)

NV9000-SE Utilities • User’s Guide 487
16. Tielines
Managing Tieline Groups
The ‘Tieline Group Details’ page appears:
Figure 16-24. Tieline Group Details Page
The ‘Tielines in Group’ section lists tielines currently included in the group. The ‘Tielines
Available’ section lists tielines not currently in any group. Each section lists details, as follows:
4 Click
X
on the window title tab to close the page.
Using Tables to View Tieline Group Details
Each table presents a unique set of information. Tielines created and updated in the ‘Tieline Group
Details’ page are reflected in these tables. These tables are for reference purposes only. Do not
change any information on these tables. To update a tieline, see
Updating a Tieline Group on page
490.
Section Description
ID Lists the ID number associated with the tieline.
Cost The numeric “weight” assigned to the tieline listed on that row. (See Costs on page
457.) If no cost is assigned, by default the cost is the sum of the “hops”—the hop
count—required to complete the route.
Name The name assigned to the tieline.
Description An optional description of the tieline.
