262
Rev 3.0 • 25 Mar 10
11. Control Panels
Adding a Control Panel
The ‘NV9604’ page appears:
Figure 11-13. NV9604 Page
2 In the ‘Panel Options’ section, select control panel behaviors from the drop-down lists:
3 In the ‘Panel Options’ section, check the ‘Use as Slave Panel’ check box to have the NV9604
act as a “slave” to an NV9602 control panel. For more information, see
Button Layout section
Button Definitions section
Panel Options section
Field
Option
Description
Default
Destination
None
After a reset, the control panel displays no destination device.
(Not recommended). See
‹device›
The Panel uses the specified device as the destination after a reset.
This also becomes the destination controlled when the control
panel is set to single destination mode.
Status Monitor
None
Selected destination used as a monitor to switch the source that is
in ‘status’ mode for the selected destination.
‹device›
High Tally
Illumination
‹number›
Controls button brightness. Press the up or down arrow to
increase or decrease the number that displays. The greater the
number, the greater the brightness; the lower the number, the
dimmer the brightness. High tally is always brighter than low
tally.
Low Tally
Illumination
‹number›
