HEIDENHAIN CNC PILOT 4290 135
4.4 Pr
ogr
am Section Code
4.4 Program Section Code
A new DIN program is already provided with section codes. You can
add new codes or delete existing ones, depending on your program
requirements. A DIN program must contain at least the MACHINING
and END section codes.
You can select further program section codes under the menu item
“PAb” (Program section code) in the main menu, in the “Instr.” menu
or in the DIN PLUS Words selection box. The CNC PILOT inserts the
section code at the correct position.
Example: Program section codes
. . . [Sections of the contour
description]
ROHTEIL [WORKPIECE BLANK]
N1 G20 X100 Z220 K1
FERTIGTEIL [FINISHED PART]
N2 G0 X60 Z0
N3 G1 Z-70
. . .
STIRN Z-25 [FRONT]
N31 G308 P-10
N32 G402 Q5 K110 A0 Wi72 V2 XK0 YK0
N33 G300 B5 P10 W118 A0
N34 G309
STIRN Z0 [FRONT]
N35 G308 P-6
N36 G307 XK0 YK0 Q6 A0 K34.641
N37 G309
. . .
For more than one independent contour definition for
drilling/milling, use the program section codes (FRONT
END, REAR END, etc.) each time.
Overview of program section codes
Program head
PROGRAMMKOPF [PROGRAM HEAD] Page 136
REVOLVER [TURRET] Page 137
SPANNMITTEL [CHUCKING EQUIPMENT] Page 142
Contour definition
KONTUR [CONTOUR] Page 143
ROHTEIL [WORKPIECE BLANK] Page 143
FERTIGTEIL [FINISHED PART] Page 143
HILFSKONTUR [AUXILIARY CONTOUR] Page 144
C-axis contours
STIRN [FRONT] Page 144
RUECKSEITE [REAR SIDE] Page 144
MANTEL [SURFACE] Page 144
Workpiece machining
BEARBEITUNG [MACHINING] Page 144
ZUORDNUNG [ASSIGNMENT] Page 144
ENDE [END] Page 144
Subroutines
UNTERPROGRAMM [SUBPROGRAM] Page 145
RETURN Page 145
Others
CONST Page 145
