68
3.3 T
a
ble f
o
r T
ools and Chuc
king Equipment
Setting up a tool list
In “Setup tool list” you can declare the tool list independently from the
data of an NC program.
Entering a tool
Select Setting up > Tool list > Compile list
Select the tool location.
Entering the tool directly:
Press ENTER (or the INS key). The CNC PILOT opens the “Setup”
dialog box
Enter the ID number and click OK to close the dialog box.
Select the tool from the database:
List the tools by type mask, or
List the tools by ID number mask
Place the cursor on the nominal tool.
Insert the tool.
