6.2 Pr
ogr
am Head
As of software version 625 952-05: In the templates, you can use the
following constant designators, which will be replaced by data from
TURN PLUS: :
Die Bearbeitungszyklen werden für jeden Bearbeitungsblock in ein
internes Unterprogramm geschrieben. The following syntax is used
for generating the subprogram names:
„ $Snn where:
„ $ = slide number
„ S = spindle number (0 to 3)
„ nn = Operation number
?-TP_MINFD-? Minimum inside diameter of the finished part
?-TP_MAXFD-? Maximum outside diameter of the finished part
?-TP_FINL-? Length of the finished part
?-TP_MINFZ-? Minimum finished part coordinate, 1st setup
?-TP_MAXFZ-? Maximum finished part coordinate, 1st setup
?-TP_MINRD-? Minimum outside diameter of workpiece blank at the end of the 1st setup
?-TP_MAXRD-? Maximum inside diameter of workpiece blank at the end of the 1st setup
?-TP_RAWL-? Length of workpiece blank at the end of the 1st setup
?-TP_MINRZ-? Minimum coordinate of workpiece blank at the end of the 1st setup
?-TP_MAXRZ-? Maximum coordinate of workpiece blank at the end of the 1st setup
?-TP_CLAMD1-? Clamping diameter, main spindle
?-TP_INCLA1-? Clamping length, main spindle
?-TP_OUTCLA1-? Free length, main spindle
?-TP_CLAMD2-? Clamping diameter, opposing spindle
?-TP_INCLA2-? Clamping length, opposing spindle
?-TP_OUTCLA2-? Free length, opposing spindle
?-TP_MAXG026-? Maximum speed, spindle 0
?-TP_MAXG126-? Maximum speed, spindle 1
?-TP_MAXG226-? Maximum speed, spindle 2
?-TP_MAXG326-? Maximum speed, spindle 3
?-TP_ZPZ1-? Datum shift, main spindle
?-TP_ZPZ2-? Datum shift, opposing spindle
?-TP_ZPOZ-? Datum offset
