HEIDENHAIN CNC PILOT 4290

141

4.4 Pr

ogr

am Section Code

Turret assignment as tool list

In the “Set up tool list” function, the CNC PILOT provides the turret
assignment as a tool list for editing. The procedure is the same as in
the “set up list” function (see “Setting up a tool list” on page 68)

U

Select “Head > Set up tool list”

U

Place the cursor on the position to be edited

U

Edit the tool entry

Soft keys

Delete tool

Take the tool from the clipboard

Delete the tool and put it in the
clipboard

Edit the tool parameters

Entries in the tool database—sorted
by type

Entries in the tool database—sorted
by ID number
