Opposing spindle—full-surface machining of a workpiece
(ID 518 289-01):
„ Spindle synchronism (G720)
„ Parting control (G917, G991, G992)
„ Traversing to a dead stop (G916)
„ Mirroring and converting (G30)
In-process measurement—measuring on the machine
(ID 354 536-01):
„ With touch trigger probe
„ For tool setup
„ For workpiece measurement
Post-process measurement—measuring on external measuring
stations
(ID 354 537-01):
„ Connecting the measuring equipment over the RS-232 interface
„ Evaluating the measurement results in the NC program
Y axis (ID 354 138-01)
„ Support of Y axis programming in DIN PLUS, TURN PLUS and in
simulation
„ Depiction of programming in the XY (front/rear face) and YZ (lateral
surface view) planes
„ DIN PLUS and TURN PLUS: Drilling, boring and figure patterns; any
milling contours
„ DIN PLUS: Cycles for drilling, boring and milling
„ TURN PLUS: Interactive or automatic generation of the working
plan, including Y-axis machining
B axis (ID 589 963-01)
„ Support of B axis programming in DIN PLUS and in simulation
„ The coordinate system is transformed to a tilted place in order to
describe hole and figure patterns as well as any desired contours in
the YZ plane
„ Fixed cycles work in a tilted plane
Options can usually be retrofitted. Your machine manufacturer can
give you more information.
This description covers all options. The operating
sequences described in this manual may therefore deviate
from those on your machine whenever a certain option is
not supported by your system.
