HEIDENHAIN CNC PILOT 4290 579
7.
4 Contr
o
l P
a
ra
met
e
rs
Control parameters for simulation
Parameters for simulation
20 Time counting for general simulation
These times are used as nonmachining times for the time calculation function.
Evaluation: Time calculation (Simulation mode)
„ Tool change time [sec]
„ Gear shifting time [sec]
„ Time allowance for M functions [sec]: All M functions are rated with this time. If an M function is also
specified in control parameter 21, the time allowances entered here are added.
21 Time counting for simulation: M function
Declare individual time allowances for a maximum of 10 M functions.
Evaluation: Time calculation in simulation mode
„ 1..10. M function: Number of M function
„ Time allowance [sec]: Individual time allowance. The time calculation function in simulation mode adds the
specified time to the time allowance entered in control parameter 20.
22 Simulation: Default window size (X, Z)
The simulation function adapts the window size to the workpiece blank. If no blank part is programmed, the
CNC PILOT uses a standard window size.
Evaluation: Simulation mode
„ Zero position X: Distance of the origin of the coordinate system from the lower window frame
„ Zero position Z: Distance of the origin of the coordinate system from the left window frame
„ Delta X: Vertical expansion of the graphics window
„ Delta Z: Horizontal expansion of the graphics window
23 Simulation: Standard workpiece blank
If no blank part is programmed, the CNC PILOT uses a standard blank.
Evaluation: Simulation mode
„ Outside diameter
„ Workpiece blank length
„ Right edge of blank part (oversize), reference: Workpiece zero point
„ Inside diameter for hollow cylinders, solid blanks: 0
