1.3 Expansion Stages (Options)
The machine manufacturer configures the CNC PILOT according to
the capabilities of the specific lathe. The following upgrades (options)
are available, which enable you to adapt the control to your specific
requirements:
TURN PLUS – Basis (ID 354 132-01):
„ Graphically supported interactive contour definition
„ Graphic program entry for describing the workpiece blank and
finished part
„ Geometry program for calculating and depicting contour points for
which dimensional data are missing
„ Simple entry of standardized form elements such as chamfers,
rounding arcs, undercuts, recesses, threads, fits
„ Simple handling of transformations such as datum shift, rotation,
mirroring, duplication
„ Graphically supported interactive DIN PLUS program generation
„ Individual selection of the operating mode
„ Selection of the tool and specification of cutting data
„ Direct graphic verification of the metal removing operation
„ Direct compensation capability
„ Automatic DIN PLUS program generation
„ Automatic tool selection
„ Automatic generation of the working plan
TURN PLUS – C-axis option (ID 354 133-01):
„ Depiction of programming in the XC plane (front/rear face) and ZC
plane (unrolled lateral surface view)
„ Hole pattern and figure pattern; any milled contours
„ Interactive or automatic generation of the working plan, including C-
axis machining
TURN PLUS – option for opposing spindles
(ID 354 134-01):
„ Rechucking with expert program
„ Interactive or automatic generation of the working plan, including
rechucking and machining the second setup
TURN PLUS – DXF import (ID 526 461-01):
„ In TURN PLUS, read in the contours (blank and finished part
contours, milled contours, contour trains) that are available in DXF
format
„ View and select DXF layers
„ Load DXF contour into TURN PLUS
