HEIDENHAIN CNC PILOT 4290 583
7.
5 Set-Up P
a
ra
met
e
rs
7.5 Set-Up Parameters
Recommendation: Use “Cur. Para > Set-up (menu) – ... ”
to edit the parameters. In the other menu items the
parameters are listed without the axes.
Set-up parameters
Workpiece datum
„ Datum position, main spindle X, Y, Z - Slide 1
„ Datum position, main spindle X, Y, Z - Slide 2
„ . . .
„ Datum position, main spindle X, Y, Z - Slide 1
„ Datum position, main spindle X, Y, Z - Slide 2
„ . . .
The CNC PILOT manages the following zero points for each slide:
„ Workpiece zero point, main spindle (reference: machine zero point)
„ Workpiece zero point, opposing spindle (reference: machine zero point, opposing spindle) The “Workpiece zero point,
opposing spindle” is derived from “Machine zero point - Zero offset” (MP 1114, 1164, ..) It is activated with “G30 H1 ...”
Notes:
„ Set the workpiece zero point in the Manual Control mode.
„ “PgUp/PgDn” switches to the next/previous slides.
Tool change position
„ Datum position, main spindle X, Y, Z - Slide 1
„ Datum position, main spindle X, Y, Z - Slide 2
„ . . .
The CNC PILOT manages the tool change point for each slide (reference: machine zero point).
Notes:
„ Set the tool change position in the Manual Control mode.
„ “PgUp/PgDn” switches to the next/previous slides.
Zero point - Oversize G53/G54/G55
„ Oversize X, Y, Z - Slide 1
„ Oversize X, Y, Z - Slide 2
„ . . .
The CNC PILOT manages allowances for zero point offsets for each slide.
“PgUp/PgDn” switches to the next/previous slides.
Zero point shift, C axis
„ Zero point shift, C axis 1
„ Zero point shift, C axis 2
Note: The zero point shift G152 is added to this parameter.
