4.28 Assignment, S
y
nc
hr
onization, W
o
rk
piece T
ransf
er
Example of machining with G62
Synchronization marking G162
G162 sets a synchronous mark. (Another slide programmed with G62
waits until the mark has been crossed.) The slide continues executing
the NC program without a pause.
Synchronous start of slides G63
G63 causes a synchronous (simultaneous) start of the programmed
slides.
. . .
$1 N.. G62 Q2 H5
Slide $1 waits until slide $2 reaches the mark 5
. . .
$2 N.. G62 Q1 H7 X200
Slide $2 waits until slide $1 reaches the mark 7 and
the position X200
. . .
Parameters
H
Number of the mark (0 <= H <= 15)
Example: Synchronization with G63
. . .
[Slides $1, $2 start simultaneously]
$1 $2 N.. G63
$1 N.. G1 X.. Z..
$2 N.. G1 X.. Z..
. . .
Ensure that no M or T commands are contained between
the NC block containing G63 and the blocks containing
traverse commands.
