HEIDENHAIN CNC PILOT 4290 365
5.1 Simulation Mode of Oper
ation
Position display:
The following boxes of the display cannot be edited:
„ N: Block number of the NC source block
„ X, Z, C: Position values (actual values)
The following display fields depend on the status line:
„ Default settings (values of the selected slide):
„ Position values (actual values)
„ Turret pocket of the active tool
„ Technology data settings:
„ Shaft speed
„ Feed rate
„ Direction of spindle rotation
Switching between standard setting and display of technology data
U Select “Set up > Status line” or press PgUp/PgDn.
Displays for slides: The slide symbols contain information on the
coordinate system and the contour currently being machined.
The control parameter 1 (settings) defines whether the
display values will be in millimeters or inches. The setting
in PROGRAM HEAD has no influence on operation and
display in the simulation mode of operation.
Slide symbols
Information of the slide symbols:
„ $n (n: 1..6): Slide designation
„ Configured coordinate system
„ Number in the coordinate system: Contour that this
slide is currently machining
„ The symbol of the selected slide is marked
You can switch slides by soft key.
