Basics of operation
Window contents:
„ In the left window
„ File transfer: CNC PILOT-specific files
„ Parameters/operating resources: Files in “internal format”
„ In the right window
„ File transfer: Files of the communications partner
„ Parameters/operating resources: Files in ASCII format
(PARA_USR or BACKUP directory)
Mark files: When using data transfer and organization functions, you
mark the file(s) you want to transfer or edit. If no file is marked, the file
on which the cursor is currently placed is selected automatically.
For each file: Place the cursor on the desired file.
Press the soft key or + (plus key). The CNC PILOT
marks the selected file.
Press again to unselect a marked file.
By touchpad: Mark the file by clicking the left or right mouse button.
Click again to unselect a marked file.
The CNC PILOT marks all displayed files.
Press again to unselect the marked files.
Mask files: The CNC PILOT displays only files that match the selected
file type and mask.
Press the soft key. The CNC PILOT opens the “Mask
of files” dialog box.
Set the mask of files:
“File type” field: Press the “Continue” key and select the file type.
“Sort” field: Choose whether you want to sort the files by name or
date.
“Mask” field: Enter the mask.
