Accessories
User functions
CNC PILOT 4290 – Accessories
DataPilot
PC software for programming and training for the CNC PILOT 4290
lathe and turning center control:
Programming and test runs
Program management
Operating resource management
Backup
Training
Electronic handwheel
HR 410 Portable Handwheel
Standard functions
CNC PILOT 4290
DIN editor
Programming in DIN 66025 format
DIN PLUS
Setup information on workpiece blank, workpiece material, tools,
chucking equipment
Extended set of commands (IF...THEN...ELSE; WHILE...;
SWITCH...CASE)
Dialog-guided user input and help graphics for each programming
function
Subprograms and variable programming
Program verification graphics for workpiece blank and finished part
Parallel programming
Parallel simulation
Alphanumeric program name
Cycles for contour description
Standard workpiece blanks
Recesses
Undercuts
Threads
Hole patterns on the face and lateral surface (XY and ZY planes)
Figure patterns on the face and lateral surface (XY and ZY planes)
Fixed cycles
Area clearance cycles, longitudinal and transverse
Recessing cycles, radial and axial
Recess turning cycles, radial and axial
Undercut cycles
Parting cycle
Thread cycles, radial and axial (multiple threads, successive threads,
taper threads, variable pitch)
Drilling, deep-hole drilling, and tapping cycles (conventional/rigid),
radial and axial (C axis and Y axis)
Contour milling and pocket milling, radial and axial (C axis and Y axis)
Area milling, centric polygon milling radial and axial (Y axis)
