358
4.41 DIN PLUS T
e
mplat
e
s
From this data, the CNC PILOT generates the following program sequence:
[===== SUBPROGRAM ====]
UNTERPROGRAMM “SCHRU1“ [SUBPROGRAM]
Call the subprogram with the entered SP name
N 2 G714 ID ““ [TOOL]
Slide 1 to spindle 3
N 3 G396 S100 G395 F0.05 M303 [TECHNOLOGY]
N 4 G0 [APPROACH POSITION]
N 5 M107 [COOLANT ON]
N 6 G47 P3 [SAFETY CLEARANCE]
N 7 G810 NS.. NE.. ...
G function with entered parameters
N 8 M109 [COOLANT OFF]
N 9 G14 Q1 [MOVE TO THE TOOL CHANGE POSITION]
RETURN
